Casing kompak tercanggih di pasaran telah hadir di sini. COUGAR QBX hadir untuk menaklukkan dunia dengan tiga senjata besar dalam bodinya yang ringkas: Dimensinya, potensi ekspansinya, dan pendinginannya yang tak tertandingi.
Kompak
Dapat Diperluas: Grafik yang Kuat
Dapat Diperluas: Penyimpanan Besar-besaran + ODD
|
Model Name |
QBX |
|
|---|---|---|
|
Case Form Factor |
Mini-ITX Case |
|
|
Motherboard Type |
Mini-ITX |
|
|
Dimension (WxHxD) |
7.01 x 11.46 x 15.12 (in) |
|
|
Optical Disk Drive (ODD) Type |
Supports ONLY Slot Loading Slim ODD |
|
|
3.5" Internal Drive Bay (HDD) |
1 |
|
|
2.5" Drive Bay (HDD/SSD) |
4 |
|
|
Expansion Slots |
2 |
|
|
I/O Panel |
2 x USB3.0/HD audio |
|
|
Cooling System Max. Supported Installation: |
Front |
80mm fan x 1 (optional) |
|
Top |
120mm fans x 2 (optional) |
|
|
Rear |
90mm fan x 1 (pre-installed) |
|
|
Bottom |
120mm fans x 2 (optional) |
|
|
Left Side |
120mm fan x 1 |
|
|
Cable Management System |
Cable feedthrough on the motherboard tray for easy routing and hiding of cables. |
|
|
Fan Filter (Cleanable) |
1 x Bottom Filter (pre-installed and removable) |
|
|
Water Cooling Support |
Left Side：240mm radiator with a single 120mm fan |
|
|
Max. Graphics Card Length |
350mm (Support for High-End Graphics Cards) |
|
|
Max. CPU Cooler Height |
105mm |
|
|
PSU |
PS2 ATX Type |
|
|
Max. PSU Length |
140 mm / 5.5 (in) |
|
|
Compatible PSU |
supports the following COUGAR PSU series: |
|
| Informasi Produk | |
|---|---|
| Berat | 12010 gram |
| Panjang | 40 cm |
| Tinggi | 31 cm |
| Lebar | 19 cm |
